AHT10, a new generation of temperature and humidity sensor, has established a new standard in size and intelligence: it is embedded in a dual-row flat no-lead SMD package suitable for reflow soldering, with a bottom surface of 4 x 5mm and a height of 1.6mm. The sensor outputs a calibrated digital signal in a standard I  2 C format. AHT10 is equipped with a newly designed ASIC dedicated chip, an improved MEMS semiconductor capacitive humidity sensor element and a standard on-chip temperature sensor element. Its performance has been greatly improved or even exceeded the reliability level of the previous generation of sensors. A generation of temperature and humidity sensors have been improved to make their performance more stable in harsh environments.

characteristic:

1. Module size: 16*11 mm

2. Interface type: I ² C

3. Working voltage: 1.8-6.0 V

4. Interface size: 4*2.54mm pitch

5. Humidity accuracy: typical ±2%

6. Humidity resolution: 0.024%

7. Temperature accuracy: typical ±0.3℃

8. Temperature resolution: 0.01℃ typical

9. Working temperature: -40℃–85℃
