DESKRIPSI SINGKAT
The US-100 ultrasonic distance measurement module can realize the non-contact distance measurement function of 2cm~4.5m , has a wide voltage input range of 2.4~5.5V , static power consumption is less than 2mA , and has a temperature sensor to correct the distance measurement results. With GPIO , serial port and other communication methods, with watchdog inside, stable and reliable work.
SPESIFIKASI
|
Electrical parameters |
US-100 Ultrasonic Ranging Module |
|
Operating Voltage |
DC 2.4V~5.5V |
|
Quiescent Current |
2mA |
|
Operating temperature |
-20~+70 degrees |
|
output method |
Level or UART (jumper selection) |
|
Sensing angle |
Less than 15 degrees |
|
Detection distance |
2cm-450cm |
|
Detection accuracy |
0.3cm+1% |
|
Serial port configuration in UART mode |
Baud rate is 9600 , start bit is 1 bit, stop bit is 1 bit, data bit is 8 bits, no parity, no flow control. |
